Description
Item No: ACE-XXSA
Specifications: | |
Current Rating: | 3A |
Dielectric Withstanding Voltage: | 1000V AC/Minute |
Contact Resistance: | 20 Milliohms Max. |
Insulation Resistance: | 5000 Megohms Min. at 500V DC |
Temperature Ronge: | -55°C To +85°C |
Insertion Force: | 340 Grame Max per Pair |
Withdrawal Force: | 28 Grams Min per Pair |
Insulator: | PBT+G.F. (UL94V-0) |
Contact: | Brass, Gold Plated On Contact On Contact Area, Tin Plated On Solder Tails, Over Nickel |
RoHS Compliant |
